| Part Number : | AFB0612HHB-R00 |
|---|---|
| Manufacturer/Brand : | Delta Electronics |
| Description : | FAN AXIAL 60X15MM 12VDC WIRE |
| RoHs Status : | Lead free / RoHS Compliant |
| Quantity Available | 4494 pcs |
| Datasheets | AFB0612HHB-R00.pdf |
| Width | 15.00mm |
| Weight | 0.098 lb (44.45g) |
| Voltage Range | 7 ~ 13.8VDC |
| Voltage - Rated | 12VDC |
| Termination | 3 Wire Leads |
| Static Pressure | 0.195 in H2O (48.6 Pa) |
| Size / Dimension | Square - 60mm L x 60mm H |
| Series | AFB |
| RPM | 4500 RPM |
| Power (Watts) | 1.44W |
| Other Names | 603-1856 |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Noise | 35.0 dB(A) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Frame | Plastic |
| Material - Blade | Plastic |
| Manufacturer Standard Lead Time | 22 Weeks |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - |
| Features | Locked Rotor Sensor |
| Fan Type | Tubeaxial |
| Current Rating | 0.120A |
| Bearing Type | Ball |
| Approvals | CE, CSA, UL, VDE |
| Air Flow | 17.3 CFM (0.484m³/min) |
Delta Electronics
